$48.49
The RAM-B-107U consists of a 2.5″ diameter round base with the universal AMPs hole pattern, double socket arm and connecting Humminbird/Apelco marine adapter base. The mount is designed with a RAM 1″ diameter patented rubber ball and socket system that has adjustment points at both ends of the double socket arm; thus allowing for almost infinite adjustment and perfect viewing angles. The RAM-B-107U is a “LIGHT USE” mount, designed to hold smaller marine electronic devices.
| Weight | 0.77 lbs |
|---|---|
| Dimensions | 12 × 6 × 3 in |
| product dimensions | Overall Height: 5" |
| socket to socket length | 3" |
| hole pattern | 4-Hole AMPS: 1.181" x 1.496", 3-Hole 120-Degree: 1.812" Diameter, See Drawing |
| plate size | Fishfinder Plate: 4.25" x 3.81", Round Plate: 2.5" Diameter |
| ball size | B Size (1") |
| weight capacity | Standard Use: 2 lbs, Heavy-Duty Use: 1 lb |
| materials | Marine-grade aluminum |
| packaging type | Poly Bag |
| weight | 0.77 lb |
| components | RAM-B-107BU, RAM-B-201U, RAM-B-202U |
